Information Inquiry Machine 28.7''
AceTech provides you with high quality and stable products and services
Keyword:
Touch Screens
Classification:
Inquiry
Previous
Next
Product Introduction
● Customized, high-cost-performance touch screens, available sizes: 4.3" to 43"
● Supports various interfaces: IIC, USB, RS232, SPI
● Supports 10-point touch, waterproof, stylus, glove touch, and anti-smudge
● Cover glass thickness options: 0.55/0.7/1.1/1.8/3.0/4.0/5.0/6.0/8/10mm
● Custom AG (anti-glare), AF (anti-fingerprint), AR (anti-reflective) surface treatments, and logo/icon printing
Related parameters
| Touch Screens Parameter Table | |||||||||
| Size | Model | Sensor OD (L*W*T)(mm) |
CG OD (L*W*T)(mm) |
CG VA （L*W)(mm) |
Ink Printing | Cable Position | IC Model | Interface | Special Treatment |
| 4.3" | 1370A | 101.4*63.4*0.4 | 117.3*117.3 | 96.6*55 | Black | Top Left of the Long Edge | GT911 | IIC | None |
| 5.0" | 1002A | 118*74*0.7 | 230*230*0.7 | 110.8*62.8 | White-black | Bottom Right of the Long Edge | GT911 | IIC | None |
| 7" | 1177A | 161.76*96.65*0.4 | 173*111.5*0.7 | 155.2*86.5 | Black | Bottom Left of the Long Edge | GT911 | IIC | None |
| 7" | 1133F | 163.08*96.42*0.55 | 174.87*111.04*0.7 | 153.13*84.87 | White | Bottom Left of the Long Edge | GT911 | IIC | None |
| 7" | 1224A | 98.77*163.70*0.55 | 139.00*301.99*1.8 | 86.90*155.20 | Black | Near the Center of the Long Edge | GT911 | IIC | None |
| 10.1" | 1228D | 230.8*137.1*0.55 | 241.8*156.1*1.1 | 223.7*126.3 | Rose gold | Near the Center of the Long Edge | GT9271 ILI2131 ILI2132 | IIC/USB/SRS323 | Waterproofing, anti-fingerprint, passive pen support, etc. |
| 10.1" | 1414A | 229.10*146.10*0.55 | 335.6*170.65*1.1 | 217.18*135.96 | Black | Top Right of the Short Edge | GT9271 ILI2131 ILI2132 | IIC/USB/SRS323 | Waterproofing, anti-fingerprint, passive pen support, etc. |
| 13.3" | 1089A | 304.7*179.6*0.55 | 328.3*229.6*4.0 | 292.6*164.08 | Black | Center of the Long Edge | ILI2132 ILI2511 | IIC/USB/SRS323 | Waterproofing, anti-fingerprint, passive pen support, etc. |
| 15.6" | 915U | 358.23*209.54*0.55 | 384.60*242.10*1.1 | 344.56*193.99 | Black | Bottom Left of the Long Edge | GT9110 ILI2511 EXC3147 | IIC/USB/SRS323 | Waterproofing, anti-fingerprint, passive pen support, etc. |
| 21.5" | 1181C | 491.24*285.99*1.1 | 510.60*307.20*2.0 | 479.66*261.28 | Black Seiko | Top Right of the Long Edge | ILI2510 EXC80W60 GT2933 | IIC/USB/SRS323 | Waterproofing, anti-fingerprint, passive pen support, etc. |
| 23.8" | 1246A | 548.8*318.1*1.1 | 568.8*338.83*1.8 | 528.2*297.84 | Black | Center of the Long Edge | ILI2510 EXC80W60 GT2933 | IIC/USB/SRS323 | Waterproofing, anti-fingerprint, passive pen support, etc. |
| 27" | 1251A | 612.44*354.36*0.7 | 613.60*354.26*1.1 | 597.74*336.66 | Black+AG | Center of the Long Edge | ILI2312 EXC80W84 GT2936 | IIC/USB/SRS323 | Waterproofing, anti-fingerprint, passive pen support, etc. |
| 32" | 1466A | 719.70*414.30*1.1 | 757.12*450.60*2.0 | 699.40*393.84 | Black | Center of the Long Edge | ILI2312 EXC80W84 | IIC/USB/SRS323 | Waterproofing, anti-fingerprint, passive pen support, etc. |
| Full Lamination | |||||||||
| 8" | 1245C | 191.80*113.55*0.55 | 212.00*153.00*2.0 | 177.42*99.17 | Black+AF | Bottom Right of the Long Edge | HY4635 GT928 | IIC | Anti-fingerprint, passive pen support, etc. |
| 10.1" | 1476A | 229.27*147.32*0.4 | 248.00*164.96*1.1 | 217.18*135.96 | High aluminum black+AF | Top Left of the Long Edge | GT9271 GT2931 ILI2131 ILI2132 | IIC/USB/SRS323 | Waterproofing, anti-fingerprint, passive pen support, etc. |
| 11.6" | 1105 | 266.07*158.88*0.55 | 274.32*168.28*1.1 | 256.82*144.68 | Black | Near the Center of the Long Edge | ILI2132 ILI2511 | IIC/USB/SRS323 | Waterproofing, anti-fingerprint, passive pen support, etc. |
| 14" | 850B | 321.30*193.66*0.55 | 341.60*219.60*1.1 | 310.90*175.59 | Black | Near the Center of the Long Edge | ILI2511 EXC3147 | IIC/USB/SRS323 | Waterproofing, anti-fingerprint, passive pen support, etc. |
| 15.6" | 1364O | 355.46*206.94*0.7 | 371.16*220.79*1.1 | 342.16*191.59 | White+AF | Bottom Left of the Long Edge | GT9110 ILI2511 EXC3147 | IIC/USB/SRS323 | Waterproofing, anti-fingerprint, passive pen support, etc. |
| 28.7" | 1183E | 689.30*301.67*1.1 | 715.30*338.00*2.0 | 673.30*282.82 | Black | Top Left of the Long Edge | ILI2312 EXC80W84 | IIC/USB/SRS323 | Waterproofing, anti-fingerprint, passive pen support, etc. |
Information Inquiry Machine Touch Screen: High-Performance & Customizable Solutions
Upgrade your interactive systems with our advanced touch screen technology, designed for reliability, versatility, and superior user experience. Suitable for kiosks, industrial controls, retail displays, and more, our touch screens deliver precision and durability in any environment.
Key Features:
✔ Wide Size Range (4.3" to 43") – Fits diverse applications, from compact handheld devices to large interactive displays.
✔ Multi-Touch Support (10-Point Touch) – Enables smooth, responsive interactions for intuitive user control.
✔ Multiple Interface Options (IIC, USB, RS232, SPI) – Ensures seamless integration with different systems.
✔ Durable & User-Friendly – Features waterproofing, anti-smudge, glove touch, and stylus support for enhanced usability.
✔ Customizable Cover Glass (0.55mm–10mm Thickness) – Tailor the screen to your needs with optional AG (anti-glare), AF (anti-fingerprint), and AR (anti-reflective) coatings.
✔ Logo & Icon Printing – Brand your devices with custom printing for a professional finish.
Why Choose Our Touch Screens?
- High Sensitivity & Accuracy – Ensures fast, error-free operation.
- Robust Construction – Scratch-resistant and long-lasting for demanding environments.
- Low Maintenance – Easy to clean and resistant to dust, moisture, and fingerprints.
- Flexible Customization – Adapts to various industrial, commercial, and consumer applications.
Ideal for self-service kiosks, ATMs, medical devices, smart home panels, and industrial control systems, our touch screens combine cutting-edge technology with cost-effective performance.
